7.4.2.9 Set Limits-Based Recording Setting
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0007 0x02 0x0008 Used Ignored
0x00
Byte 8:
Recording Action:
0x00 Off (default)
0x01 Record while
limit
exceeded
0x02 Record one
scan on limit
0x03 Record
continuously
after limit
exceeded
Determines the recording action the specified cards will to take when a limit event has occurred.
7.4.2.10 Set Limits-Based Recording Mode Command
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0008 0x02 0x0009 Used Ignored
0x00
Byte 8:
Group number
Multiple groups can be
specified by logically ORing
the values:
0x01 Group A
0x02 Group B
0x04 Group C
0x08 Group D
Byte 9:
Mode
0x00 Off
0x01 Continuous
0x02 Burst
This command controls how data will be recorded on the selected cards when a limit event is triggered.
 Off - disables time-based recording for the selected group (default)
 Continuous - records data continuously,
 Burst - records data continuously in bursts
