Vishay Micro-Measurements System 7000 Programmer’s Reference Manual
Page 140 of 142
7.4.8.9 Get Control Module Information Command (Control Module)
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0006
response
length
varies
0x08 0x800A
Query Only
Ignored
0x0000
Ignored
0x00
None
See below for the values
returned as a query response
Bytes 8-46
The following null-terminated system identifier:
Vishay Micro-Measurements, System 7000\0
Byte 47: Firmware Major Version
Byte 48: Firmware Minor Version
Byte 49: FPGA Device
Byte 50: FPGA Major Version
Bytes 51: FPGA Minor Version
Byte 52-59: Serial Number
Note: if the serial number is less than 8 characters it will be padded with Nulls (0x00) up to 8 characters.
Byte 60: Card Major Version
Byte 61: Card Minor Version
Byte 62: Backplane FPGA Device
Byte 63: Backplane FPGA Major Version
Byte 64: Backplane FPGA Minor Version
Byte 65: Backplane Card Version
Byte 66: Number of Backplane Card Slots
7.4.8.10 Display Flashing LED Sequence
Length Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0007 0x08 0x000B
No query
Ignored
0x00
Ignored
0x00
Byte 8:
1 – start sequence
0 – stop sequence
Causes the leds on the system 7000 front panel to begin a flashing sequence. This can be used to help
pick a particular system out of a group (e.g. sort of a “here I am” indication). .
