Vishay Micro-Measurements System 7000 Programmer’s Reference Manual
Page 137 of 142
7.4.8.2 Set IP Configuration Information
Length
Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
varies 0x08 0x0002
Ignored
0x0000
Ignored
0x00
See Below
Field Name Size (in bytes) Description
DHCP flag 2 DHCP is not supported this field must be 0x0000
Host Name 1 - 64 Must follow naming standards
Domain Name 1 - 256 Must follow naming standards
IP address 1 - 16 In IPV4 dotted-decimal notation
Subnet Mask 1 - 16 In IPV4 dotted-decimal notation
Gateway 1 - 16 In IPV4 dotted-decimal notation
DNS address 1 - 16 In IPV4 dotted-decimal notation
Multicast Data IP address 1 - 16 In IPV4 dotted-decimal notation
Multicast Event IP address 1 - 16 In IPV4 dotted-decimal notation
Command Port 2 Integer, Must be greater than or equal to 49152
(49142, default)
Online Data Port 2 Integer, Must be greater than or equal to 49152
(49143, default)
Event Port 2 Integer, Must be greater than or equal to 49152
(49144, default)
Offline Data Port 2 Integer, Must be greater than or equal to 49152
(49145, default)
All character fields (names and IP addresses) must be terminated with a NULL (0x00) character and may
vary in length. All character fields are optional, but you must insert a single NULL as a placeholder.
7.4.8.3 Get Free Space Command
Length
Command
Group
Command
Code
Card Mask Channel
Mask
Parameters
0x0006 0x08 0x8004
Query Only
Ignored
0x0000
Ignored
0x00
None
Query returns the amount of free space available on the compact flash drive on the control module. The
value is a 64-bit integer representing the number of available bytes.
