18
Name – A descriptive title/name for the event that will help identify it from other events. Type in the description and hit
[Enter] to move to next field.
Level – Setup the VS4820 speaker level for this event. Use the Up/Down arrow keys to select one of four audio levels:
Low, Medium, High, or Maximum level.
Mode – Select the radio communication mode between Live audio or playback of a pre-recorded voice message stored
on the VS4820. Use Up/Down arrow keys to select the mode or pre-programmed (01-99) voice message.
Auto – Enable/disable the event activation style. If enabled, the event will be initiated instantly, (when activated)
without any additional user confirmation. If the Auto mode is disabled, the user will need to confirm the call
before any data is being transmitted.
CTCSS – Select a PL/CTCSS tone for channel privacy mode when needed. Use Up/Down arrow keys to select the right
tone value or None to disable.
TX Channel – Select the transmitter RF channel for this event, if other than the default channel, in cases where the
VS4820 base station operates on more than one frequency.
Use the Left/Right arrow keys to navigate between the fields. Use [F5] to save any changes, [F9] to delete the event (if
editing an existing event) and hit the [ESC] key to exit the screen back to the previous menu.
Digital Pager Event
The VS4820 base station can communicate with most alphanumeric (such as Visiplex VP4 pager), numeric, and voice
pagers. The VS4820 use POCSAG digital paging format for numeric & alphanumeric pagers, and 2-Tone signaling for
voice paging.
Code – A unique 7-digit activation code that can activate a single or group of pagers. Usually, Visiplex pagers include 2
user-programmable activation codes (capcodes). Use the keyboard numeric keys to enter/edit the activation
code.
Type – Select the pager type: Alphanumeric, Numeric or Voice pager. Use the Up/Down arrow keys to select the pager
type.
Baud- Select the POCSAG data baud rate for the digital pager. Use the Up/Down arrow keys to select from 512 BPS,
1200 BPS or 2400 BPS.
