SUPREMA - OPERATION & SERVICE MANUAL
Page 36 of 58 02-2012 Suprema - Operation & Service
Transferring Settings From One Suprema to Another
Using the VKI Data Link downloader, it is possible to for you to transfer all the settings from
one Suprema coffee maker, to one or several other Suprema coffee makers. For example, if a
customer requests three Suprema coffee makers with the exact same settings, only one needs to
be set up. Once the first unit is programmed, the settings can be loaded into the Data Link, and
then downloaded from the Data Link to the other two units. This will eliminate the need to
repeatedly program multiple units with the same settings. All the settings in the "
SET-UP" mode
will be transferred, with the exception of the counters.
To transfer settings from one Suprema coffee maker to another, the procedure outlined below
must be performed. This needs to be done with the power to the coffee machine "
ON".
Step 1 – Transferring Settings to the Data Link Device
1. Connect the Data Link phone jack harness to the free connector on the
back of the front board.
2. Press the "SET-UP" button on the back of the front board.
a) The following message will appear on the display,
3. Press the bottom scroll button to the right of the "START" button.
a) The following message will appear on the display,
4. Press the "START" button on the Suprema front selection panel.
a) The settings in the Suprema "
SET-UP" will now be transferred to the
Data Link device.
COPY DATA LINK
TO SET-UP
COPY SET-UP TO
DATA LINK
Note:
Although the
identical settings
will be transferred
from a pre-
programmed unit to
a non-programmed
unit, some fine-
tuning may be
required for product
and water settings.
This is due to slight
differences with the
tolerances of certain
components, such
as valves, motors
and ingredient
dispensers.
