Removing the Water Tank Assembly
1. Switch the coffee maker "OFF".
2. Drain the water tank.
a) Place a heat-resistant and leak-proof container beneath the water tank.
b) Remove the top clip on the drain plug and push the drain plug upwards. The bottom
clip will act as a stopper.
3. Remove the brewer.
4. Disconnect the inlet hose.
a) Remove the hose clamp securing the inlet hose to the inlet fitting.
5. Remove the valve cover on the water tank.
6. Remove the hose from the hot water valve.
7. Remove the hose fitting from the whipper motor (if installed).
8. Disconnect the water tank harness from the rear board.
9. Disconnect the temperature probe harness from the rear board.
10. Disconnect the wires identified in the table below.
*For more information about wiring, consult the
wiring section of this manual.
11. Carefully slide the water tank forward and out of the machine.
Wire #3-2 on Fuse Box Harness
Ground Stud on Rear Board Cover
CAUTION: Water coming out of the water tank may be extremely hot. Use
caution when removing the outlet valves.
