SUPREMA - OPERATION & SERVICE MANUAL
Suprema - Operation & Service 02-2012 Page 49 of 58
Removing the Ingredient Dispenser
1. Switch off the power to the machine.
2. Remove the brewer.
3. Slide the water tank outward. The water tank wrap supports the right side of the
ingredient dispenser base
4. Release the ingredient dispenser bracket support on the left wall of the cabinet.
a) Remove the screw securing the bracket to the left wall of the cabinet.
b) Rotate the support backwards until it is horizontal. The ingredient dispenser will
now drop.
5. Raise the ingredient dispenser lid on top of the coffee maker.
6. Remove the ingredient dispenser.
Installing the Ingredient Dispenser
1. Position the drive pins of the motor so they are all vertical.
2. Position the drive couplings of the ingredient dispenser so that they are vertical.
3. Place the ingredient dispenser on the ingredient dispenser bracket.
a) Make sure the ingredient lid is up and the ingredient dispenser couplings and motor
drive pins mate.
4. Slide the water tank forward. The water tank wrap supports the right side of the
ingredient dispenser base.
5. Secure the bracket support on the left wall of the cabinet.
a) Rotate the bracket support on the left wall of the cabinet forward so that it lifts the
ingredient dispenser base, and secure with a screw.
6. Replace the brewer.
7. Switch the coffee maker "ON".
8. Close the ingredient dispenser lid.
