SUPREMA - OPERATION & SERVICE MANUAL
Page 50 of 58 02-2012 Suprema - Operation & Service
Removing the Ingredient Dispenser Motor
1. Remove the ingredient dispenser.
a) Refer to the "
Removing Ingredient Dispenser" instructions in this manual.
2. Remove the brewer bracket.
3. Disconnect the wires to the ingredient motors.
4. Remove the ingredient dispenser bracket.
a) Pull up on the ingredient dispenser bracket to free it from the joggle on the back
wall of the cabinet.
b) Pull the dispenser bracket towards the front of the cabinet and remove.
5. Remove the two screws that secure the motor to the bracket (located above the
drive pin).
6. Slide the motor down and out of the bracket.
Installing the Ingredient Dispenser Motor
1. Slide the motor into the back of the bracket from underneath
2. Replace the two upper screws.
3. Connect the appropriate wires to the motors.
a) Wires #3 and #12-2 are for the large section of the ingredient dispenser (coffee).
Wires #4 and #12-1 are for the small section (decaf).
4. Install the ingredient dispenser bracket.
5. Install the ingredient dispenser.
a) Refer to the "
Installing Ingredient Dispenser" instructions in this manual.
6. Install the brewer bracket.
7. Install the brewer.
Removing the Front Circuit Board
1. Open the inner door.
2. Disconnect any harnesses connected to the front board.
3. Remove the front board assembly.
a) Remove the two screws securing it in position (located at the top corners of the
board assembly on the inside of the front door).
4. From the outside of the door, lift and remove the front board.
Installing the Front Circuit Board
1. Place the front board assembly (bottom first) onto the outside of the front door.
2. Secure the front board assembly in place.
a) Install the two screws to secure it into position (located at the top corners of the
board assembly on the inside of the front door).
3. Connect the phone type cables and free vend key switch harness (if used) to the
front board.
4. Close and lock the inner door.
