SUPREMA - OPERATION & SERVICE MANUAL
Suprema - Operation & Service 02-2012 Page 43 of 58
Removing the Inlet Valve
1. Switch the coffee maker "OFF".
2. Shut off the water supply.
3. Drain the water tank completely.
4. Remove the fitting from the inlet valve at the back of the machine.
5. Disconnect the two wires that go to the inlet valve.
6. Disconnect the inlet hose from the hot water tank.
a) Remove the clamp securing the hose to the inlet fitting at the bottom of the water
tank.
b) Pull firmly on the hose to remove it.
7. Remove the screws that secure the inlet valve to the back of the machine.
Installing the Inlet Valve
1. Make sure the coffee maker is switched "OFF".
2. Position the valve in place and secure it with the two screws.
3. Replace the two wires onto the inlet valve.
a) Wires #6-1 and #7-1.
4. Secure the hose (using a hose clamp) to the inlet at the bottom of the water tank.
5. Connect a fitting to the inlet valve at the back of the machine.
6. Turn on the water supply.
7. Switch the coffee maker "ON".
8. Inspect for any leaks.
