Resistance
Range Resolution Accuracy
60.0Ω* 0.01Ω ±(1.3% + 3)
600.0Ω* 0.1Ω ±(1.3% + 3)
6.000kΩ 0.001kΩ
±(1.0% + 3)60.00kΩ 0.01kΩ
600.0kΩ 0.1kΩ
6.000MΩ 0.001MΩ ±(1.6% + 4)
60.00MΩ 0.01MΩ ±(3.0% + 7)
Overload protection 1000 V
Measuring voltage: approx. -0.5 V, measuring current approx. -0.7 mA
*Accuracy after deduction of the measuring line resistance
Capacity
Range Resolution Accuracy
6.000 nF* 0.001 nF ±(4% + 13)
60.00 nF* 0.01 nF
±(4% + 7)
600.0 nF* 0.1 nF
6.000 µF* 0.001 µF
60.00 µF 0.01 µF
600.0 µF 0.1 µF
6.000 mF 0.001 mF
±13%
60.00 mF 0.01 mF
Overload protection 1000 V
*Accuracyformeasurementrange≤1µFonlyvalidwiththeRELfunctionused
Frequency “Hz” (electronic)
Range Resolution Accuracy
600 Hz - 6.000 kHz* 0.001 kHz
±(0.1% + 5)
60.00 kHz 0.01 kHz
600.0 kHz 0.1 kHz
6.000 MHz 0.001 MHz
40.00 MHz 0.001 MHz
Signal level (without direct voltage share):
≤100kHz:200mV-30Vrms
>100 kHz - <1 MHz: 600 mV - 30 Vrms
≥1MHz-<10MHz:1V-30Vrms
10 MHz -40 MHz: 1.8 V - 30 Vrms
*The frequency measuring range starts at 600 Hz
