Volvo A25E - Page 93

Operating techniques
Hauler chassis 93
Activate the hydraulics / load and dump brake
Hauler chassis are either equipped with standard hydraulics or
optional hydraulics. The hydraulics as well as the load and dump
brake are activated in different ways.
Check the function in the manual for the superstructure.
Activating standard hydraulics as well as load and dump
brake
Use the tipping control (A) to activate the hydraulics and the button
(B) to apply the load and dump brake.
Activating optional hydraulics as well as load and dump
brake
Use switch (C) to activate the hydraulics, and switch (D) to apply
the load and dump brake.
Rear window, wiper and washer
(optional equipment)
The rear window's wiper and washer are activated with switch (E).
S
T
O
P
r
/
m
i
n
C
1046068
1046067
A
1046066
B
P
P
l
D
1046069
E
1046070
1046071
