Operating techniques
94 Hauler chassis
Bolted joint on rear frame extension, check-
tightening
The bolted joint shall be check-tightened by a Volvo CE authorised
workshop at the 100 hour warranty inspection, and thereafter
every 2000 hours.
Tightening torque: 952 Nm
Fuses (under control panel)
Relays (under control panel)
Marking Rated current Description
1 5 A Frame oscillating brake
2 10 A Wiper and washer, rear window
Marking Description
1 Frame oscillating brake
2 Wiper and washer, rear window
RE1
RE2
FU2
FU1
1048513
