SPECIFICATIONS
618
Towing capacity and towball load
Towing capacity and towball load for driving with
a trailer can be read in the tables.
Max. weight braked trailer
NOTE
Use of vibration dampers on the towbar is
recommended for trailers heavier than 1800
kg.
Engine
Engine code
A
Gearbox Max. weight braked trailer (kg) Max. towball load (kg)
T5 AWD B4204T14 Automatic
2100
110 (160
B
)
T5 AWD B4204T18 Automatic
2100
110 (160
B
)
T5 AWD B4204T36 Automatic
2100
110 (160
B
)
D4 AWD D4204T12 Automatic
2100
110 (160
B
)
A
The engine code, component number and serial number can be found on the engine.
B
160 kg only applies to Australia.
IMPORTANT
When driving with a trailer, it is permitted to
exceed the vehicle's gross vehicle weight
(including towball load) by a maximum of
100 kg (220 lbs), provided that speed is lim-
ited to 100 km/h (62 mph). National legal
requirements for the vehicle combination,
such as speed, etc. must be observed.
