16
There are three main steps to installing the VanWeigh® system:
• Install the display unit. The display unit must be installed in the cab of the vehicle and
connected to the vehicles power supply. The external domain cable must be routed from the
display unit to the junction box. See “How to install the display unit” on page 18.
• Junction box installation. This must be installed on the chassis of the vehicle. It must be
located in an appropriate position between the suspension systems and the cab of the vehicle.
The sensor and display unit cables must be able to reach the junction box.
• Sensor installation. The type of sensors you install will depend on the suspension systems in
operation on the vehicle. Air pressure transducers are installed on air suspension systems.
Axle transducers are installed on steel axle suspension systems. The sensors must be
installed in an appropriate position on the suspension system and their cables must be routed
back to the junction box.
It is recommended that the display unit is installed rst, followed by the junction box and
sensors. However, these steps can be performed in any order.
