How to calibrate the junction box

Use the display unit installed in the cab to calibrate the VanWeigh® system after it has been

congured.

1. Tap the conguration icon in the home page to open the conguration menu

2. Tap Vehicle Conguration to open the vehicle conguration menu

3. Tap Calibration to open the junction box calibration menu:

4. Tap the Type value to select the type of zero and span calculation to use. Select Axle to input

the weight measurements of each axle. Select Wheel to input the weight measurements of

each wheel.

Wheel calibration is only possible when using wheel weigh pads. For the purposes of this

manual, it is assumed that the axle type is used to perform the calibration.

Juncon Box

Type

Axle Zero

Axle Span

1 - 1

Axle

Juncon Box Calibraon

1/1
