Introduction and scope
VanWeigh® is an overload monitoring system for use on twin axle vehicles with mechanical or air
suspension systems.
Scope
This document is intended as a guide to the installation and commissioning of VanWeigh®.
It covers two transducer types currently supported in a VanWeigh® system:
• VanWeigh® axle transducers. These measure suspension deection on mechanical spring
suspension systems
• Air pressure transducers. These measure changes to air pressure on air suspension systems
Di󰀨erent system congurations can be used to support di󰀨erent chassis types. The system can be
congured to use either type of transducer and any combination of the two.
About this document
Any display screenshots used in this document are intended as an illustration of the function being
described. As such, any specic detail or settings shown will di󰀨er from one installation to another.
The documentation uses the following conventions:
Important. These are important notes and appear inside a green border
Caution. These notes warn of an operation that may cause damage to the VanWeigh®
system. These notes appear inside an orange border
Warning. These notes warn of an operaon that may cause injury to the installer. The note is
highlighted in a yellow banner
