Typical system schematics
Below are two examples of system schematics showing where the junction box and transducers
are tted in relation to the vehicle. These are two example schematics, but a variety of
congurations may be used.
Leaf Spring Air Spring
Truck Air
System
Truck Air
System
VanWeigh®
Display unit
Junction Box and
Axle Transducers
Suspension
Air Bags
Air
Transducers
Leaf Spring Leaf Spring
VanWeigh®
Display unit
Junction Box and Axle Transducers
