VanWeigh II Specification
Axle overload protection for light commercial vehicles with a GVW of up to 7.5t (RoW), 16535lbs
(US)
PARAMETRS MINIMUM TYPICAL MAXIMUM UNIT
SYSTEM
Accuracy Better than 2.5% 90 - 110% of Full
scale
Capacity (GVW) Up to 7.5 Tonne
16535 lbs.
Operating voltage 9 36 VDC (US and
RoW)
Operating
temperature
-40 70 °C
-40 158 °F
Current at
24V/12V (4 x
transducers)
189/340 mA
Current standby
at 24V/12V
3/3 mA
Weighing modes Gross, Axles
INDICATOR
Type A Si TFT RGB
Screen Size 95.04 (W) x 53.86 (H) mm
3.74 x 2.24 (4.3 diagonal) inches
Outline
Dimension
105.50 (W) x 67.20 (H) x 4.20 (D) mm
4.15(W) x 2.65 (H) x 0.17 (D) inches
Operating
temperature
-40 to +70 °C
-40 to +158 °F
Environmental
protection
IP45
Resolution 480x272 Dots
Dot pitch 0.198 mm
0.0078 inches
Signal input port Microt 24 way connector
Expansion port
VanWeigh
®
