System configuration table
Junction box:_________________________________________________
Orientation:__________________________________________________
Axle Sensors
Vehicle Le Side
Vehicle Right Side
Axle No.
Type
Sensor Type
Orientation
Serial No.
Sensor Type
Orientation
Serial No.
1
2
It is recommended that you photocopy this table and use it to record the details of the sensors on
your vehicle.
If a single sensor used to monitor both sides of an axle, enter its details in the vehicle left side
columns and leave the vehicle right side columns blank.
