WARNING / MESSAGE DESCRIPTION
Warning Sensor Missing! System unable to nd all congured sensors.
Tap icon for more information.
Check connections.
Note: System will continue to function, once
message has been displayed, using the missing
sensor’s last weight reading.
Warning Sensor Reboot! System has found a previously missing sensor
and rebooted.
Note: A system power cycle will be needed to
clear icon.
Unknown Error General error message when system
congured incorrectly.
JBox Orientation Compensation Not Set Junction box orientation has been left as ‘Un-
congured’. Set orientation and save.
Un-congured JBox Detected Axles Sensors
Zero Span.
Axles Sensors Zero Span. This message
indicates that a junction box has been detected
but the axles and sensors have not been
congured, and the zero and span calibrations
have not been done.
Un-congured JBox Detected Zero Span. Zero Span. This message indicates that a
junction box has been detected, the axles and
sensors have been congured, but the zero and
span calibrations have not been done.
Un-congured JBox Detected Span. Span. This message indicates that a junction
box has been detected, the axles and sensors
have been congured and the zero calibration
has been done, but the span calibration has not
been done.
Sensor Voltage too low Check output voltage in Diagnostics, Voltages
& Temperatures, Junction Box. Output voltage
should be close to 8V.
Input voltage should be close to the vehicle
supply voltage.
Temperature over range Check location of junction box (too close to heat
source)
Check location of display (too close to heat
source)
