Chapter 4: Description of functions (abbreviated)
48
P5.14
Corresponding setting of
FI curve 1 minimum
input
-100.0% to +100.0%
0.0%
☆
P5.15
FI curve 1 maximum
input
P5.13 - +10.00V
10.00V
☆
P5.16
Corresponding setting of
FI curve 1 maximum
input
-100.0% to +100.0%
100.0%
☆
P5.17
FI filter curve time 1
0.00s to 10.00 s
0.10s
☆
P5.18
FI curve 2 minimum
input
0.00V - P5.20
0.00V
☆
P5.19
Corresponding setting of
FI curve 2 min. input
-100.0% to +100.0%
0.0%
☆
P5.20
FI curve 2 maximum
input
P5.18 - +10.00V
10.00V
☆
P5.21
Corresponding setting of
FI curve 2 max. input
-100.0% to +100.0%
100.0%
☆
P5.22
FI filter curve time 2
0.00s to 10.00 s
0.10s
☆
P5.23
FI curve 3 minimum
input
-10.00V to P5.25
-10.00V
☆
P5.24
Corresponding setting of
FI curve 3 min. input
-100.0% to +100.0%
-100.0%
☆
P5.25
FI curve 3 maximum
input
P5.23 - +10.00V
10.00V
☆
P5.26
Corresponding setting of
FI curve 3 max. input
-100.0% to +100.0%
100.0%
☆
P5.27
FI filter curve time 3
0.00S - 10.00s
0.10s
☆
