Chapter 4: Description of functions (abbreviated)
54
P7.01
Select the function of
the JOG key
0: The JOG button is off
1: Switches between panel control and
external control (terminal command channel
or communication channel):
2: Switching between FORWARD and REVERSE
3: FORWARD JOG
4: BACK JOG
P7.02
STOP/RESET key
0: STOP/RESET key enabled only in operation
panel control
1: STOP/RESET key enabled in any operation
mode
1
☆
P7.03
Parameters 1, LED
display during RUN
0000-FFFF
Bit00: Run frequency 1 (Hz)
Bit01: Set frequency (Hz)
Bit02: Bus voltage (V)
Bit03: Output voltage (V)
Bit04: Output current (A)
Bit05: Output power (kW)
Bit06: Output torque (%)
Bit07: Input status S
Bit08: Output status M01
Bit09: FIV voltage (V)
Bit10: FIC voltage (V)
Bit11: Reserved
Bit12: Counter value
Bit13: Length value
Bit14: Display load speed
Bit15: PID setting
1F
☆
