VYBO Electric Vector V810 - Page 59

Chapter 4: Description of functions (abbreviated)
55
P7.04
Parameters 2, LED
display during RUN
0000-FFFF
Bit00: PID feedback
Bit01: PLC status
Bit02: Pulse frequency setting (kHz)
Bit03: Run frequency 2 (Hz)
Bit04: Remaining run time
Bit05: FIV voltage before correction (V)
Bit06: FIC voltage before correction (V)
Bit07: Reserved
Bit08: Linear speed
Bit09: Current time under voltage
Bit10: Current run time (Min)
Bit11: Pulse frequency setting (kHz)
Bit12: Communication setting value
Bit13: Reserved
Bit14: Display of main frequency X (Hz)
Bit15: Auxiliary frequency Y (Hz) display
0
☆
P7.05
LED display during STOP
0000-FFFF
Bit00: Set frequency (Hz)
Bit01: Bus voltage (V)
Bit02: Input status S
Bit03: Output status M01
Bit04: FIV voltage (V)
Bit05: FIC voltage (V)
Bit06: Reserved
Bit07: Counter value
Bit08: Length value
Bit09: PLC status
Bit10: Display load speed
Bit11: PID setting
Bit12: Pulse frequency setting (kHz)
33
☆
P7.06
Load speed display
coefficient
0.0001- 6.5000
1.0000
☆
