V 810 Chapter 5 Checking and removing errors
84
External
equipment
fault
EF
1: External fault signal is input
via X.
2: External fault signal is input
via virtual I/O.
1: Reset the operation.
2: Reset the operation.
Communi-
cation fault
CE
1: The host computer is in
abnormal state.
2: The communication cable is
faulty.
3: P028 is set improperly.
4: The communication
parameters in group PD are
set improperly.
1: Check the cabling of host
computer.
2: Check the communication
cabling.
3: Set P028 correctly.
4: Set the communication
parameters properly.
Contactor
fault
rAy
1: The drive board and power
supply are defective.
2: The contactor is defective.
1: Replace the defective drive
board or power supply board.
2: Replace the defective
contactor.
Current
detection
fault
IE
1: The HALL device is
defective.
2: The drive board is defective.
1: Replace the defective HALL
device.
2: Replace the defective drive
board.
Motor auto-
tuning error
TE
1: The motor parameters are
not set according to the
nameplate.
2: The motor auto-tuning
times out.
1: Set the motor parameters
according to the nameplate
properly.
2: Check the cable connecting
the inverter and the motor.
PG card error
PG
1: The set encoder type is
incorrect.
2: The cable connection to the
encoder is incorrect.
3: The encoder is damaged.
4: The PG card is faulty
1: Set the correct encoder type
2: Eliminate external faults.
3: Replace the damaged
encoder.
4: Replace the faulty PG card.
EEPROM read
/ write fault
EEP
The EEPROM chip is defective.
Replace the main control
board.
