Specifications
6.14 Dimensions model 5001
Fig. 96: Machine dimensions (model 5001)
Main data
Model 5001
Dead weight
4750 kg (7099 lbs.)
Overall height
2830 mm (9' 3'')
Overall height with dumped-out dump bucket
3630 mm (8' 6'')
Overall height without rollbar
2030 mm (6' 7'')
Overall width
1920 mm (6' 3'')
Ground clearance
290 mm (1')
Wheelbase
2110 mm (6' 9'')
Outside turning radius
4100 mm (13' 5'')
Hill climbing ability
50 % theoretically
Safe authorized inclination
25 % in all drive positions
