6-10 BA 5001-6001 US – Edition 1.2 * * 6001b610.fm
Specifications
6.16 Dimensions model 6001S (swivel dump bucket)
Fig. 98: Machine dimensions (model 6001S)
Main data
Model 6001S
Dead weight
4240 kg (9348 lbs.)
Overall height
3080 mm (10' 1”)
Overall height with dumped-out dump bucket
3660 mm (12')
Overall height without rollbar
2300 mm (7' 7”)
Overall width
2215 mm (7' 3”)
Ground clearance
380 mm (15”)
Wheelbase
2485 mm (8' 2”)
Outside turning radius
5500 mm (18' 1”)
Hill climbing ability
50 % theoretically
Safe authorized inclination
25 % in all drive positions
