BA 5001-6001 US – Edition 1.2 * 6001b610.fm 6-11
Specifications
6.17 Dimensions model 6001S (swivel dump bucket) with cab
Fig. 99: Machine dimensions (model 6001S with cab)
Main data
Model 6001S
Dead weight
4320 kg (9524 lbs.)
Overall height
2990 mm (9' 10”)
Overall height with dumped-out dump bucket
3670 mm (12')
Overall height without cab
2300 mm (7' 7”)
Overall width
2215 mm (7' 3”)
Ground clearance
380 mm (15”)
Wheelbase
2485 mm (8' 2”)
Outside turning radius
5500 mm (18' 1”)
Hill climbing ability
50 % theoretically
Safe authorized inclination
25 % in all drive positions
