Disassembly Procedures WM 130/170/270 Repair
wc_tx000379gb.fm 44
8.6 Removing Ignition Coil, Starter Pulley, and Flywheel
See Graphic: wc_gr001764
8.6.1 Remove the spark plug cap (a) from the spark plug. Remove the
screws (b) securing the ignition coil (i) and remove the ignition coil.
8.6.2 Remove the starter pulley (d) from the flywheel (e). If necessary, place
a socket wrench (f) over the pulley nut (c) and strike the wrench with a
hammer (g) to loosen the nut.
NOTICE: Do not insert a screw driver or other prying tool between the
flywheel blades. Damage to the blades may occur.
8.6.3 Using a puller (h), remove the flywheel from the crankshaft.
