WAGNER GM 4700AC User Manual

3
GM 4700AC
OPERATING MANUAL
VERSION 06/2014 ORDER NUMBER DOC2311730
Table of Contents
1 ABOUT THIS MANUAL 6
1.1 Preface 6
1.2 Warnings, Notices, and Symbols in this Operating Manual 6
1.3 Languages 7
1.4 Abbreviations 7
1.5 Terminology for the Purpose of this Manual 8
2 CORRECT USE 9
2.1 Device Type 9
2.2 Type of Use 9
2.3 Use in Potentially Explosive Areas 9
2.4 Safety Parameters 9
2.5 Processible Working Materials 10
2.6 Reasonably Foreseeable Misuse 10
2.7 Residual Risks 11
3 IDENTIFICATION 12
3.1 CE Explosion Protection Identi cation 12
3.2 Identi cation "X" 12
3.3 Type Plate 13
4 GENERAL SAFETY INSTRUCTIONS 14
4.1 Safety Instructions for the Operator 14
4.1.1 Electrical Equipment 14
4.1.2 Sta Quali cations 14
4.1.3 Safe Work Environment 14
4.2 Safety Instructions for Sta 15
4.2.1 Safe Handling of WAGNER Spray Devices 15
4.2.2 Grounding the Device 16
4.2.3 Product Hoses 16
4.2.4 Cleaning and Flushing 17
4.2.5 Handling Hazardous Liquids, Lacquers and Paints 17
4.2.6 Touching Hot Surfaces 18
5 DESCRIPTION 19
5.1 Design 19
5.2 Mode of Operation 20
5.3 Protective and Monitoring Equipment 20
5.4 Scope of Delivery 20
5.4.1 Versions for Application up to 25 MPa; 250 bar; 3625 psi 20
5.4.2 Standard Equipment 20
5.5 Data 21
5.5.1 Materials of Paint-wetted Parts 21
5.5.2 Technical Data 21
6 ASSEMBLY AND COMMISSIONING 22
6.1 Training Assembly/Commissioning Sta 22
6.2 Storage Conditions 22
6.3 Installation Conditions 22
6.4 Assembly and Installation 23
6.4.1 Typical AirCoat Spraying System 23

WAGNER GM 4700AC Specifications

General

Brand	WAGNER
Model	GM 4700AC
Category	Paint Sprayer
Language	English
