WAGNER GM 4700AC User Manual

70
GM 4700AC
OPERATING MANUAL
VERSION 06/2014 ORDER NUMBER DOC2311730
14.2 SPARE PARTS GM 4700AC
Spare parts lists GM 4700AC
DesignationOrder No. Order No.
1
1 --- 2313585
GM 4700AC 25 MPa NPSM1/4"
2
1 9999501 9999501
Helical spring on the product side
3 1 9999500 9999500 Helical spring on the air side
4 1 2312140 2312140 Tension sleeve
5
1 394335 -
Spring cap 16 MPa; 160 bar; 2320 psi
5
1 - 394333
Spring cap 25 MPa; 250 bar; 3625 psi
6
1 394924 394924 Air tappet, complete
8 1 2311320 2311320 Valve rod unit, complete
10
1 394327 394327
Sealing screw
11 1 394328 394328 Sealing collar
11 1 2324747 2324747 Sealing collar UHMW-PE, complete (including pos 12)
12 1 9971445 9971445 O-ring
13 1 379xxx 379xxx AC nozzle (see Chapter 13.4)
13 1 321xxx 321xxx AC nozzle plus (see Chapter 13.5)
14 1 394339 394339 Sealing ring
15 1 9974245 9974245 O-ring
16 1 394922 394922 Valve housing, complete
17 1 394338 394338 Nozzle seal
18 1 2312149 2312149 Collet chuck
19 1 394257 394257 Valve tappet, complete
20 1 394318 394318 Nut
21
1 394601 394601
Trigger guard
22
1 394319 394319
Screw
23
1 394334 394334
Safety clip
24
1 9935088 9935088
Parallel pin
25
1 394313 394313
Air tappet
26
1 9974243 9974243 O-ring
27
1 394303 394303
Mounting bracket
28 1 9921906 9921906 Lock washer
29
1 2324766 2324766
Air swivel, complete
34 1 394920 394920 Valve rod, complete
35 1 394323 394323 Rod seal
36 1 2313494 2313494 Air cap LV plus (red)
36 1 2313497 2313497 Air cap HV plus (blue)
36 1 2313498 2313498 Air cap LA plus (bronze)
50 1 394309 394309 Valve tappet
51 1 179338 179338 Air valve seal
52 1 179395 179395 Seal
= Wearing part
= Included in service set
= Not part of the standard equipment but available as a special accessory.
