Operating manual Manual system SPRINT 2
6 Assembly and commissioning
32 Order number 2467031 | Edition 04/2024
9. Connect the mobile base's grounding cable (17) to the grounding connection of the
control unit.
10. Connect the control cable (18) from the solenoid valve on the control unit.
11. Connect the feed air hose and dosing air hose (19) from the injector to the control unit
according to the color coding.
