WAGO I/O System 750 Series User Manual

I/O Modules • 109
WAGO-I/O-SYSTEM 750
DeviceNet
750-506, 753-506
The 750-506, 753-506 digital output module has 2-bits of diagnostic informa-
tion for each output channel. The 2-bit diagnostic information can then be de-
coded to determine the exact fault condition of the module (i.e., overload, a
short circuit, or a broken wire). The 4-bits of diagnostic data are mapped into
the Input Process Image, while the output control bits are in the Output Proc-
ess Image.
Input Process Image
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Diagnostic
bit S 3
Channel 2
Diagnostic
bit S 2
Channel 2
Diagnostic
bit S 1
Channel 1
Diagnostic
bit S 0
Channel 1
The output modules seize 4 Instances in Class (0x65).
Output Process Image
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
not used not used
controls
DO 2
Channel 2
controls
DO 1
Channel 1
And the output modules seize 4 Instances in Class (0x66).
4 Channel Digital Output Modules
750-504, -516, -519, -531, 753-504, -516, -531, -540
Output Process Image
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
controls
DO 4
Channel
4
controls
DO 3
Channel
3
controls
DO 2
Channel
2
controls
DO 1
Channel
1
The output modules seize 4 Instances in Class (0x66).
4 Channel Digital Output Modules with Diagnostics and Input Process
Data
750-532
The 750-532 digital output modules have a diagnostic bit for each output
channel. When an output fault condition occurs (i.e., overload, short circuit, or
broken wire), a diagnostic bit is set. The diagnostic data is mapped into the
Input Process Image, while the output control bits are in the Output Process
Image.
