122 • I/O Modules
WAGO-I/O-SYSTEM 750
DeviceNet
Input and Output Process Image
Instance Byte Destination Remark
C/S Control/Status byte
ID Command byte
D0
D1
D2
n
D3
Data bytes
The specialty modules represent 1x6 bytes input data and seize 1 Instance in
Class (0x67).and seize 1 Instance in Class (0x68).
DALI/DSI Master Module
750-641
The DALI/DSI Master module has a total of 6 bytes of user data in both the
Input and Output Process Image (5 bytes of module data and 1 byte of con-
trol/status). The following tables illustrate the Input and Output Process Im-
age, which have 6 bytes mapped into each image.
Input Process Image
Instance Byte Destination Remark
S Status byte
D0 DALI response
D1 DALI address
D2 Message 3
D3 Message 2
n
D4 Message 1
The specialty modules represent 1x6 bytes input data and seize 1 Instance in
Class (0x67).
Output Process Image
Instance Byte Destination Remark
C Control byte
D0 DALI command, DSI dimming value
D1 DALI address
D2 Parameter 2
D3 Parameter 1
n
D4 Command-Extension
And the specialty modules represent 1x6 bytes output data and seize 1
Instance in Class (0x68).
