I/O Modules • 123
WAGO-I/O-SYSTEM 750
DeviceNet
EnOcean Radio Receiver
750-642
The EnOcean radio receiver has a total of 4 bytes of user data in both the Input
and Output Process Image (3 bytes of module data and 1 byte of con-
trol/status). The following tables illustrate the Input and Output Process Im-
age, which have 4 bytes mapped into each image.
Input Process Image
Instance Byte Destination Remark
S Status byte
n
D0
D1
n+1
D2
Data bytes
Output Process Image
Instance Byte Destination Remark
C Control byte
n
-
-
n+1
-
Not used
The specialty modules represent 2x2 bytes input and output data and seize 2
Instances in Class (0x67) and 2 Instances in Class (0x68).
MP Bus Master Module
750-643
The MP Bus Master Module has a total of 8 bytes of user data in both the In-
put and Output Process Image (6 bytes of module data and 2 bytes of con-
trol/status). The following table illustrates the Input and Output Process Im-
age, which have 8 bytes mapped into each image.
