4.6.2.1.5 Assembly Object (0x04):
Instance 0:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
1 required get Revision UINT Revision of the Assembly Object,
Range 1-65535, class definition
upon which the implementation is
based.
0x0002
Description of the Instances:
Instance
ID
Description
1 References to the process image containing analog and digital output data.
2 References to the process image containing only digital output data.
3 References to the process image containing only analog output data.
4 References to the process image containing containing analog and digital input data plus status.
5 References to the process image containing only digital input data plus status.
6 References to the process image containing only analog input data plus status.
7 References to the process image containing analog and digital input data.
8 References to the process image containing only analog input data.
9 References to the process image containing only analog input data.
12 References to the process image: analog and digital input data plus Error Code
13 References to the process image: analog and digital input data plus Error Code and Error Argument
14 References to the process image: analog and digital input data plus Error Code and Error Argument,
Status
15 References to the process image: Status plus three zero bytes and analog and digital input data
Instance 1:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
3 dep. on kind
of connected
modules
get/set Process
Array of
Byte
process image, collection of all
modules process output data.
Instance 2:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
3 dep. on kind
of connected
modules
get/set Process
Array of
Byte
process image, collection of all
modules process output data.
Instance 3:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
3 dep. on kind
of connected
modules
get/set Process
Array of
Byte
process image, collection of all
analog modules process output
data.
Instance 4:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
3 dep. on kind
of connected
modules
get Process
Array of
Byte
process image, collection of all
modules process input data plus
status byte.
