WAGO I/O System 750 Series User Manual

DeviceNet • 95
Configuration / Parametering with the Object Model
WAGO-I/O-SYSTEM 750
DeviceNet
4.6.2.1.10 Discrete Output Point Object (0x66):
Instance 0:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
1 required get Revision UINT Revision of the Discrete Output
Point Object, Range 1-65535, class
definition upon which the imple-
mentation is based.
0x01
2 optional get Max
instance
UINT maximum instance number of an
object currently created in this
class level of device
0x00ff
Description of the instances:
Instance ID Description
1 Reference to the first digital output point
2 Reference to the next digital output point
...
255 Reference to the last possible digital output point
Instance 1 to 255:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
1 dep. on kind
of connected
modules
get/set DOPOBJ_
VALUE
BIT digital output bit 0:off
1:on
Services:
Service Code Service Name Description
0x0E Get_Attribute_Single Used to read a DeviceNet Object attribute
value
0x10 Set_Attribute_Single Used to modify a DeviceNet object attribute
value
4.6.2.1.11 Analog Input Point Object (0x67):
Instance 0:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
1 required get Revision UINT Revision of the Analog Input Point
Object, Range 1-65535, class
definition upon which the imple-
mentation is based.
0x0001
2 optional get Max
instance
UINT maximum instance number of an
object currently created in this
class level of device
0x0010
Description of the instances:
Instance ID Description
1 reference to the first analog input point
2 reference to the next analog input point
...
16 reference to the last possible analog input point
