WAGO I/O System 750 Series User Manual

96 • DeviceNet
Configuration / Parametering with the Object Model
WAGO-I/O-SYSTEM 750
DeviceNet
Instance 1 to 16:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
1 dep. on kind
of connected
modules
get AIPOBJ_
VALUE
Array of
Byte
Input data actual
input
Values
2 dep. on kind
of connected
modules
get AIPOBJ_
VALUE
USINT Input data length Number
of Bytes
Services:
Service Code Service Name Description
0x0E Get_Attribute_Single Used to read a DeviceNet Object attribute
value
0x10 Set_Attribute_Single Used to modify a DeviceNet object attribute
value
4.6.2.1.12 Analog Output Point Object (0x68):
Instance 0:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
1 required get Revision UINT Revision of the Analog Output
Point Object, Range 1-65535, class
definition upon which the imple-
mentation is based.
0x01
2 optional get Max
instance
UINT maximum instance number of an
object currently created in this
class level of device
0x0010
Description of the instances:
Instance ID Description
1 reference to the first analog output point
2 reference to the next analog output point
...
16 reference to the last possible analog output point
Instance 1 to 16:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
1 dep. on kind
of connected
modules
get AOPOBJ_
VALUE
Array of
Byte
output data actual
output
value
2 dep. on kind
of connected
modules
get AOPOBJ_
VALUE
USINT output data length number
of Bytes
Services:
Service Code Service Name Description
0x0E Get_Attribute_Single Used to read a DeviceNet Object attribute
value
0x10 Set_Attribute_Single Used to modify a DeviceNet object attribute
value
