DeviceNet • 97
Configuration / Parametering with the Object Model
WAGO-I/O-SYSTEM 750
DeviceNet
4.6.2.1.13 Module Configuration (0x80):
Instance 0:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
1 required get Revision UINT Revision of this Object. 1 (0x0001)
2 optional get Max
instance
UINT maximum number of instances -
Description of the instances:
Instance ID Description
1 reference to the first analog module (coupler/controller)
2 reference to the next connected module (I/O module)
...
16 reference to the last possible connected module (I/O module)
Instance 1 to 65:
Attribute
ID
Used in
buscoupler
Access
rule
Name Data type Description Value
1 dep. on kind
of connected
modules
get ModulDe-
scription
WORD Description of the connected
modules
(Instance 1 = Coupler/Controller,
Instance 2 = Module 1,...)
Bit 0: Module with inputs,
Bit 1: Module with outputs,
Bit 8-14: Data width internal in
bits
Bit 15: 0/1 Analog/Digital module,
For analog modules the bits 1-14
describe the type of module i. e.
460 for the module 750-460
actual
output
value
Services:
Service Code Service Name Description
0x0E Get_Attribute_Single Used to read a DeviceNet Object attribute
value
