SURFOX 306 USER MANUAL
2.4. Device components
1 Display 8 Alarm LED (red)
2 Voltage decrease button 9 Black socket for marking wand
3 MODE button 10 Black socket for DW wand
4 Voltage increase button 11 Red socket for ground cable
5 SET button 12 Main switch (ON/OFF)
6 Power button 13 Ground cable
7 Power LED (green)
