Walter SURFOX 306 - How to Install the Accessories

12
1
2
3
M5X25
M5X10
SURFOX 306 USER MANUAL
2.5. How to install the accessories
1. WAND HOLDER
• Align the wand holder with the proper holes on the left side
of the unit.
• Use a 3 mm hex key (included) to tighten the two mounting
screws.
• The longer screw (M5X25) must be installed in the top
hole.
• The shorter screw (M5X10) must be installed in the lower
hole.
Included hex keys
(5 mm and 3 mm)
