Walter SURFOX 306 - Electrical Installation

36
A
C
B
D
SURFOX 306 USER MANUAL
7.6. Electrical installation
• Use the supplied cable to carry out the electrical installation of the DW wand; connect the female connector (A) to the DW
wand (B) and insert the male connector (C) into the designated socket on the front panel of the device (D).
