Walter SURFOX 306 - Technical Specifications

57
SURFOX 306
USER MANUAL
14. TECHNICAL SPECIFICATIONS
Model SURFOX 306
Part number 54-D 316 54-D 336
Input voltage 120 V - 50/60 Hz 230 V - 50/60 Hz
Input power 1200 W 2400 W
Input current 10 A
Output voltage 3÷30 V
Output voltage adjustment 1 V
Output current adjustment LOW, MID, HIGH
Reservoir capacity 1.8 l
Dispensing speed 1÷3.6 l/h
Pump adjustments
Dynamic
Manual
Auto
(8 levels)
Input air pressure min: 80 PSI max: 150 PSI
Insulation class IP21S
Noise level <70 dB (A)
Weight
(empty) 47 lb (21.5 kg)
Dimensions 15.5" x 14.5" x 21" (390 x 365 x 535 mm)
Wands
Blowing wand
DW wand *
Marking wand *
Functions
Cleaning
Polishing
Marking
* optional
