Fluid-Handling Components 26
1
1.1 Fluid-Handling Components
Before installing a Waters 1525 Pump, become familiar with its fluid-handling components,
as illustrated in Figure 1-3
and Figure 1-4.
Figure 1-3 Fluid-Handling Components in the Waters 1525µ Pump
Gradient
Mixer
Inlet
Manifold
Restrictor
Tee
(Patent Pending)
Pressure
Transducer
Pulse Dampeners
(Covered by Shroud)
Pump Head
Assembly
Draw-Off
Valve
Drip Tray Waste Exit
Drip Tray
Waste Line
Vent Valve
Pump Outlet
Vent Valve
Inlet Check
Valve Assembly
Outlet Check
Valve Assembly
Indicator Rod
