Waters 1525M - Chapter 2 Installing the 1525 Pump; 2.1 Selecting the Site

Selecting the Site 31
2
Chapter 2
Installing the 1525 Pump
This chapter lists the site requirements for a Waters 1525 Pump, and describes how to
unpack the pump, make electrical connections, and make fluidic connections.
2.1 Selecting the Site
Install the pump at a site that meets the specifications indicated in Table 2- 1.
Figure 2-1
shows the dimensions of a 1525 Pump.
Table 2-1 Installation Site Requirements
Factor Requirement
Temperature 4 to 40 °C (39 to 104 °F)
Relative humidity 20 to 80%, noncondensing
Bench space Width: 17 in. (43 cm) including bottle holder
[24 in. (61 cm) with column heater]
Depth: 24 in. (61 cm)
Height: 17 in. (43 cm)
Vibration Negligible
Clearance Minimum 6 in. (15 cm) at rear for ventilation and cable
connections
Static electricity Negligible
Input voltage and
frequency
Grounded AC, 120/240 VAC, 50/60 Hz, single phase
Electromagnetic fields No nearby source of electromagnetic noise, such as arcing
relays or electric motors
Power requirements 200 VA for pump
150 VA for column heater
STO
P
Attention:
To avoid overheating and to provide clearance for cable connections, make
sure there is at least 6 in. (15 cm) of clearance at the rear of the pump.
