1.2 Electronic Components
Before installing the Waters 1525 Pump, become familiar with its electronic components
as illustrated in Figure 1-5
.
Figure 1-5 Rear Panel Electronic Components in the Waters 1525 Pump
Ethernet Port
Power Cord
Power Switch
Fuse Holder
(Side of Unit)
I/O Terminal Block
IEEE-488 Port
IEEE-488 Address
Switches
Cooling Fan Vent
RS-232 Port
(reserved for future use
)
(for service use only)
Power Module
Connection
