Specifications 88
A
Appendix A
Specifications
This appendix provides the following specifications for the Waters
®
1525 Pumps:
• Physical
• Environmental
• Electrical
• Performance
Table A-1 Physical Specifications for 1525 Pumps
Item Specification
Height
Depth
Width
Weight
17.0 in (43 cm)
24.0 in (61.0 cm)
12.0 in (30.5 cm) (not including bottle holder)
60.0 lb (27.2 kg)
Wetted surface material 316 stainless steel, sapphire, reinforced fluorocarbon
polymer seals (1525µ Pump), UHMWPE seals
(1525EF Pump), carbon-reinforced Tefzel
®
Table A-2 Physical Specifications for the Column Heater
Item Specification
Height
Depth
Width
Weight
17.0 in (43 cm)
14.0 in (35.5 cm)
6.0 in (15.2 cm)
13 lb (5.9 kg)
