Waters 1525M - Pump Dimensions

Installing the 1525 Pump 32
2
Figure 2-1 Pump Dimensions
24 in.
12 in.
17 in. (43 cm)
7 in.
5 in.
Clearance for
Optional Column
Heater
Clearance for
Bottle Holder
(61 cm)
