C.4.2.1 Micro cart power connections
Figure C–6: Micro cart power connections
Note: The connection between the connector and the Ethernet switch, detector, µSM-FL, and
µBSM is one meter each. The connection between the connector and the ASM is two meters. A
universal IEC coupler runs between the connector and detector.
Ethernet switch
Detector
µSM-FL
µBSM
ASM
µBSM
TVM
AC line
