Table 3–3: Run LED indications (continued)
LED mode and color Description
Steady red Indicates a failure of a module that prevents its
further operation. Power-off the module, and
then restart it. If the LED is still steady red,
contact your Waters service representative.
Flashing red and green Used as a visual identification of a module
after it is selected via the console.
3.1.5.3 TVM: Run LED
The Run LED, located on the right side of the power LED on the TVM’s front panel, indicates the
run status.
Table 3–4: Run LED indications
LED mode and color Description
Unlit Module is idle.
Steady green The TVM is operating normally and attempting
to complete any outstanding samples. When
sample requests are finished, the LED reverts
to the unlit mode.
Flashing green Initializing and preparing for normal operation.
Flashing red Error state. Refer to the instrument console for
information about the error.
Steady red Indicates a failure of a module that prevents its
further operation. Power-off the module, and
then restart it. If the LED is still steady red,
contact your Waters service representative.
Flashing red and green Used as a visual identification of a module
after it is selected via the console.
3.2 Starting the instrument console
The instrument console is a software application that provides a way to configure settings,
monitor performance, run diagnostic tests, and maintain the system and its modules. It replaces
the keypads and small-screen displays traditionally found on the front of system modules. The
instrument console functions independently of data applications and does not recognize or control
them.
