Waters ACQUITY UPLC M-Class - 1.2 System components

Figure 1–4: 2D, 300 µm ID scale configuration
Solvent tray
µBinary solvent manager
Trap valve manager
µSample manager - fixed loop
µBinary solvent manager
Auxiliary solvent manager
Micro cart
1.2 System components
The capabilities of the ACQUITY UPLC M-Class system depend on the components installed.
The following sections briefly describe the system components and their functions.
1.2.1
System features
Review M-Class system features:
November 26, 2019, 715003588 Revision C
Page 15
